6-Layer PCB Manufacturing | TG170 2.0mm Board | ENIG 2U” RoHS | SMT+DIP PCBA | PCB Assembly

6-Layer PCB Manufacturing | TG170 2.0mm Board | ENIG 2U” RoHS | SMT+DIP PCBA | PCB Assembly | 2oZ Copper Thickness

Detailed Specifications

Material	TG170
Board Thickness	2.0mm
Surface Treatment	ENIG
Copper Thickness	2/1/1/1/1/2 oz
Soldermask	Green
Silkscreen	White
The Min Laser Drill Hole	6Mill
Panel	Mouse Bite

Product Description

1.PCB Assembly Services Overview

Product : Multilayer Printed Circuit Board (Multilayer PCB) designed for security equipment applications.
Order Flexibility : Prototype, small, medium, and large-volume production supported. No MOQ required for new orders.
Certifications : Full compliance with UL, IATF 16949 (automotive), RoHS, ISO 9001, and other industry standards.

2.Specification Of PCB Assembly Service

CATEGORY	PARAMETER	SPECIFICATIONS	TECHNICAL NOTES
Substrate	Layers	1-20 Layers	Complies with IPC-4101 Class 2 standards
	Material	FR-4,CEM-1/3 ,High Tg (>170°C), Halogen-Free FR4,FR-1/2, Aluminum Core PCB	Thermal Conductivity of Aluminum Core PCB ≥2.0 W/(m·K)
	Board Thickness	0.2mm-7mm	Tolerance: ±10%
Fabrication	Max. Board Size	500mmx500mm	Supports Panelization
	Min. Drill Hole Size	0.25mm	Mechanical Drilling (Minimum drill bit size: 0.25mm)
	Min. Line Width/spacing	0.075mm(3mil)	Supports High Density Interconnect (HDI)
Surface Finish	Surface Finish	HASL(Lead-Free HASL), Chemical Tin, ENIG, lmmAg,OSP, Gold Plating	ENIG (Electroless Nickel Immersion Gold): Nickel thickness 3-5μm, Gold thickness 0.05-0.1μm (per IPC-4552)
	Solder Mask Color	Green/Black/white/Red/Blue/Yellow	Matte/Gloss Finish available
	Copper Thickness	0.5-4oz (17-140um)	Outer layer copper thickness ≥1 oz (35μm)
Tolerance	PTH Hole Tolerance	±0.076mm	Complies with IPC-6012 Class 2
Tolerance	NPTH Hole Tolerance	±0.05mm
Packing	Inner Packing	Vacuum Sealing + ESD Bag	Moisture Sensitive Devices (MSDs) controlled per MSD Level 3 (IPC/JEDEC J-STD-033)
Packing	OuterPacking	Standard Carton	ptional anti-shock padding or custom wooden crate
Certifications	Certificates	UL,ISO9001.IS014001. ROHS.CQC	Supports lead-free process (IPC J-STD-001)
Profiling	Profiling Method	Routing、V-CUT、Beveling	V-CUT depth controlled to ±0.1 mm (when board thickness is 1.6 mm)
Assembly	Assembly Service	ull-range PCBA OEM/ODM Services	SMT placement accuracy ±0.025 mm (Cpk ≥1.33), DIP insertion yield ≥99.95%; Support for ICT/FCT testin

3.PCB Assembly(SMT) Product Capacity

CAPABILITY CATEGORY	TECHNICAL SPECIFICATIONS
SMT Capacity	Max. PCB Size: 510mm x1200mm(SMT Process)
	Supported Components: 0201.0402.0603.0805.1206
	Packages
	Min. lC Pin Pitch: 0.1mm
	Min. BGA Pitch: 0.1mm
	IC Placement Accuracy
	+0.01mm(CPK=1.67)
	Daily Capacity: ≥8 MillionPoints/Day (Dual Shifts)
DIP Capacity	3 Full-Automatic DlP Lines(Wave Soldering/SelectiveSoldering)
Testing Services	Standard Tests	.Bridgeest .AOl Inspection .X-Ray Analysis .FlyingProbe
	Functional Tests	.In-CircuitTest (lCT) .Functional Test(FCT) .Thermal Cycling
	Reliability Tests	.DropImpact (lEC 60068-2-32) .Burn-In (72H@85°C/85%RH)
	Custom Tests	.WaterproofTest(lP67/P68) .LeakageCurrent Test (s0.1mA)

4.Products Application:

1. Telecom & Communication
2. Consumer Electronics
3. Security & Surveillance
4. Automotive Electronics
5. Smart Home & IoT
6. Industrial Control & Automation
7. Medical Devices
8. Military & Defense
9. New Energy Systems
10. Renewable Energy & Power

5.OEM/ODM/EMS Services for PCBA

1. Design

Integrated PCBA & Enclosure Design

▪ DFM-optimized PCB layout (supports rigid-flex, HDI)

Rapid Prototyping

▪ Rapid PCB/PCBA prototyping (SMT+PTH+BGA mixed assembly)

2. Advanced Manufacturing

PCB Assembly

▪ High-precision SMT (Supported Components: 0201.0402.0603.0805.1206, 0.1mm pitch BGA)

▪ Dual-line PTH assembly with selective wave soldering

Structural Fabrication

▪ Plastic injection molding (ABS/PC/PMMA, ±0.15mm tolerance)

▪ Precision sheet metal stamping (aluminum/steel, CNC deburring)

3. Supply Chain Management

Component Procurement

▪ Procurement of Component BOM List

4. Testing & Validation

Automated Quality Control

AOI、 Online testing (ICT), functional testing (FCT)

5. Logistics & Compliance

Global Trade Services

▪ HS code classification & customs clearance optimization

6.FAQ

Q1: Are you a factory or a trading company?

A: We are a direct electronics manufacturer based in Shenzhen, China, with full in-house production capabilities.

Q2: Do you accept sample orders?

A: Yes, we accept sample orders for product verification. Customized prototyping and functional testing are available upon request.

Q3: What is your warranty policy?

A: We offer a 24-month warranty covering defects caused by non-human factors (e.g., manufacturing or material flaws). Replacement or repair services will be provided upon validation.

Q4: What payment terms do you accept?

A: We accept 100% T/T (Telegraphic Transfer) for all orders. Other payment methods can be negotiated for long-term partnerships.

Q5: What is the lead time for bulk orders?

A: Standard lead time ranges from 20 to 35 working days , depending on order complexity and quantity. Expedited production options are available for urgent projects.

If you have PCB design, prototyping, or mass production needs, feel free to share your Gerber files,BOM lists or technical specifications,
and we will provide the optimal solution!
📞 Contact Us:
- Email: [hjpcbassemblysmt@gmail.com]
- Phone: [18929375891]

Looking forward to collaborating with you! 🚀
